Hanmey Flail Mulching Mower 1.25m
Overview
These mowers use heavy-duty hammer flails and perform extremely well in long grass, rough areas mulching grass, and small scrub, but still leaving a great finish cut on lawn grass. This Hanmey Flail mower is of excellent quality and superior to all we have experienced in its price range. This 1.25m size is ideal for 28-45 hp tractors however on the smaller compact tractors you will need to check stability due to the weight as this is a heavy machine for its size. We do a lighter version of this for sub-compact tractors. One of the main advantages of this model is that the rear door can be opened to help eject large volumes of grass and get easy access for maintenance.
Features & Benefits
- Deck and components are CNC laser cut giving superior quality control, with perfect alignment maximising the life span of bearings belts etc.
- Electronically balanced rotor shaft, resulting in smooth operation without vibration
- 4mm deck, 6mm sides,8mm skids, 10mm steel used for 3-point linkage
- Front steel guard flaps with rear roller
- Zinc-plated 8.8-grade bolts and nylock nuts
- Fixed offset linkage so you can get closer to fence lines or trees
- Thick durable quality powder coating and zinc-plated fasteners.
- Purpose-built gearbox with built-in overrun clutch and lifting
- Adjustable rear roller and skids
- Adjustable rear opening panel for high output of grass, and ease of maintenance
- Spiral Flail configuration on the rotor for higher performance at low HP
Specifications
| Specifications |
Units |
|
Overall Width |
1400mm |
| Cutting Width | 1250mm |
| Depth | 790mm |
|
Overall Height |
900mm |
| Weight | 266kg |
| Offset dimensions | 605 left of centre: 645 right of centre |
| Linkage 3 pt linkage | Category 1-2 |
| Number of hammers | 20 |
| Tractor power range | 18 -30HP |
| RPM | 540 |
| Rotor diameter and thickness | 108 x 8 |
| Rotor speed | 2295 rpm |
| Number of Belts | 3 |
| PTO | Series 5, with shear bolt |
|
Steel thickness |
8 mm |
| Mower deck thickness | 4mm |
| Side thickness | 8mm |
Notes
Made by Hanmey in China, assembled by our experts and delivered by Mainfreight fully assembled
2 year warranty
