Hanmey 1.25m Flail Mulching Mower for Sub Compact tractors
OVERVIEW:
This is a lighter version of the popular Hanmey 1.25m Flail mower, making it ideal for Sub Compact Tactors which have a low lifting capacity before the front wheels start coming off the ground. Ideal for tractors like John Deere, 1023 or 1025R Kubota BX2380 or BX2680 Kioti CS2610 etc
FEATURES AND BENEFITS:
-The EFGM125 Flail Mulching Mower features a 30 Hp gearbox with built in over run clutch
-24 forged Hammer flails (slightly lighter flail than the larger Hanmey flail mower but similar design that can handle heavy growth , branches and sticks etc)
-3 drive belts with heavy duty galvanised belt cover
-Adjustable galvanised skids
-Adjustable rear roller.
-Front debris guard steel flaps to help prevent grass and debris flying forward into the tractor.
-Includes PTO shaft series 4 .900mm overall length ( will need to be shorten to suit some smaller tractors)
-Category 1 Pins, clevis range (lift arm spacing ) 710mm (outer) 615mm (inner) pin.
| Specifications |
Units |
|
Overall Width |
1360mm |
| Cutting Width | 1250mm |
| Depth | 780mm |
|
Overall Height |
850mm |
|
Overall Length including PTO |
900mm |
| Weight | 228kg |
| Mower Offset dimensions | 690mm cover-centre: 670mm outside skid - centre |
| Cutting Off-set dimensions | 518mm left of centre/ 734mm right of centre |
| Linkage 3 pt linkage | Category 1 |
| Number of hammers | 24 |
| Tractor power range | 16 HP - 35 HP Max |
| Rotor RPM | 540 |
| Rotor Speed | 2200 |
| Rotor diameter and thickness | 108 x 8 |
| Number of Belts | 3 |
| PTO | Series 4 |
|
Category 1 pins clevis range (lift arm spacing) |
710mm outer |
| 615mm inner pin | |
| Side thickness | 6mm |
| Body Thickness | 4mm |
Made by Hanmey in China, assembled by our experts and delivered by Mainfreight fully assembled
18 month waranty
