2 Row Potato Planter

OVERVIEW

This Zagroda 2 Row Potato Planter is designed and manufactured by one of Europe's leading planter manufacturers. It can also be used for planting onions and garlic etc, by using an optional small cup adaptor.

It is designed with Category 1 and 2, 3 Point Linkage

In one pass the planter performs all tasks to plant the potato it makes furrows, automatically plants the seed potatoes and forms the ridge.

Potatoes can be planted in the distance between rows 625mm / 675 mm or 700 / 750 mm And the seed can be spaced in variable distances in a row (290mm, 320 mm and 350 mm) with the adjustment of the metal wheels diameter

The planting depth is 100 - 150 mm.

FEATURES AND BENEFITS

-3-point linkage Category I or II

- Adjustable Inter-row spacing

-Tank capacity 180kg

-Rubber protection to bottom of tank

-Adjustable planting depth

-2 Ridger blades

-Metal wheels (adjustable diameter and spacing)

-Cup adaptors available for small potatoes or garlic etc



Specifications	Units
Overall Width	1480mm
Tank Capacity	180kg
Length	1000mm
Height	1550mm
Weight	208kg
Space between the rows	625mm- 675mm or 700/750mm
Distance between potatoes in the same row	290mm/ 320mm/ 350mm
Adjustable planting depth	100-150mm
Linkage	3 point linkage, Category 1 and 2



Made in the EU
