TLBES-120  Fail Mulching Mower for Excavator  8-13 ton 100LPM

Overview

The  Lipa TLBE-S-120 with Casappa 30-51 motor  suitable for 88-100 LPM Max of auxiliary hydraulic flow

The Lipa TLBE-S Excavator mounted Mulching head, is perfect for cutting/mulching grass, undergrowth, Gorse, and other saplings in those hard to reach locations ( generally up 70-100mm diameter) .

Features & Benefits

• The TLBE-S 120 can be matched to Excavators from 8-13 ton

• It has solid, well-designed construction with 10mm wall thickness and 8mm thick side plates.

• It is suitable for oil flow up to 100 LPM

• Adjustable rear roller with scraper

• Adjustable position headstock mounting

• 12 toothed Hammers

• Features zinc-plated front chain guard,  and rear rubber guards

• Powder-coated finish

• Does not come with hoses or hitch but we can supply to your requirements. price excludes excavator attachment brackets and pins.




Specifications	Units
Overall Width	1400mm
Cutting Width	1240mm
Depth	1000mm
Overall Height	720mm
Weight	370kg
Number of hammers	12
Cutting Capacity	70mm
Oil Flow Requirement	88-100 LPM
Rotor diameter and thickness	140mm x 8
Maximum hydraulic pressure	4060 PSI (280 Bar)
Number of Belts	3
Wall thickness	10mm
Cowl and side plate thickness	8mm
Motor	KM30-51 Casappa hydraulic motor
